Model |
|
Display |
Panel Size (inch) : 23.8
Pixels Per Inch (PPI) : 93
Aspect Ratio : 16:9
Display Viewing Area (H x V) : 527.04 x 296.46 mm
Display Surface : Non-Glare
Backlight Type : LED
Panel Type : IPS
Viewing Angle (CR≧10, H/V) : 178°/ 178°
Pixel Pitch : 0.2745mm
Resolution : 1920×1080
Color Space (sRGB) : 100%
Brightness (Typ.) : 300cd/㎡
Contrast Ratio (Typ.) : 1000:1
Display Colors : 16.7M
Response Time : 5ms(GTG)
Refresh Rate (Max) : 75Hz
Flicker-free : Yes
LCD ZBD Warranty : Yes(3 yr) |
Video Feature |
Trace Free Technology : Yes
ProArt Preset : Standard
ProArt Preset : sRGB
ProArt Preset : DCI-P3
ProArt Preset : Rec. 709
ProArt Preset : Scenery
ProArt Preset : Reading
ProArt Preset : Darkroom
ProArt Preset : Rapid Rendering
ProArt Preset : User mode1
ProArt Preset : User mode2
Color Temp. Selection : Yes(5 modes)
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
Gamma Adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Accuracy : △E< 2
ProArt Palette : Yes
QuickFit : Yes
HDCP : Yes, 1.4
ELMB Sync: Yes
VRR Technology : Yes (Adaptive-Sync)
Motion Sync : Yes
ProArt Chroma Tune : Yes
Low Blue Light : Yes |
Audio Feature |
Speaker : Yes(2Wx2) |
I/O Ports |
USB-C x 1 (DP Alt Mode)
DisplayPort 1.2 x 2 (Daisy Chain)
HDMI(v1.4) x 1
USB Hub : 4x USB 3.2 Gen 1 Type-A
Earphone Jack : Yes
USB-C Power Delivery : 65W |
Signal Frequency |
Digital Signal Frequency : HDMI: 30~83 KHz (H) / 48~75 Hz (V)
DisplayPort: 85~85KHz (H) / 48~75 Hz (V) |
Power Consumption |
Power Consumption : 11.07 W
Power Saving Mode : <0.5W
Power Off Mode : 0W
Voltage : 100-240V, 50/60Hz |
Mechanical Design |
Tilt : Yes (+35° ~ -5°)
Swivel : Yes (+90° ~ -90°)
Pivot : Yes (+90° ~ -90°)
Height Adjustment : 0~130mm
VESA Wall Mounting : 100x100mm
Kensington Lock : Yes |
Dimensions (Esti.) |
Phys. Dimension (W x H x D) : 53.97 x 47.18 x 21.14 cm (21.25″ x 18.57″ x 8.32″)
Phys. Dimension without Stand (W x H x D) : 53.97 x 32.99 x 5.28 cm (21.25″ x 12.99″ x 2.08″)
Box Dimension (W x H x D) : 63.20 x 45.00 x 21.60 cm (24.88″ x 17.72″ x 8.50″)
Box Dimension (W x H x D) : 72.80 x 43.50 x 15.70 cm (28.66″ x 17.13″ x 6.18″) |
Weight (Esti.) |
Net Weight : 6.3 kg (13.89 lbs)
Net Weight without Stand : 4.2 kg (9.26 lbs)
Gross Weight : 8.3 kg (18.30 lbs) |
Accessories (vary by regions) |
Color pre-calibration report
DisplayPort cable
HDMI cable
Power cord
Quick release stand
Quick start guide
USB-C cable
Warranty Card
Welcome Card
|
Certificate |
Energy Star
EPEAT Silver
TCO Certified
TÜV Flicker-free
TÜV Low Blue Light
Calman Verified |
Note |
*Box dimensions depend on actual size. |
